Resistance Tests Chart 2007

ITEM
370 cc
570 cc
500/600 cc
800/1000 cc
Ignition Coil Primary
0,26-0,35 ohm
OR-B
0,26-0,35 ohm
OR/BW
0,24-0,36 ohm
B/OR-OR/R
0,24-0,36 ohm
B/W-W/BL
Ignition Coil Secondary
6800-10.200 ohms
HT - HT
6800-10,200 om
HT - HT
6800-10.200 ohms
HT - HT
5040-7560 ohms
B/R-GR/R
Charge Coil (1)
128 - 192 ohms
R/W- B/R
12-18 ohms
B/R-G/R
7,20-10,8 ohms
B/R-GR/R
7,20-10,8 ohms
B-GR/R
Charge Coil (2)
N/A
12-018 ohms
BR/W-GR/R
7,20-10,8 ohms
BR/W-GR/R
7,20-10,8 ohms
BR/W-GR/R
Ignition timing Sensor (1)
N/A
148-222 ohms
148-222 ohms (500cc)
80,8-121 ohms (600cc)
GR/W-BR/GR
148-222 ohms
BL/W-BR/GR
Ignition Timing Sensor (2)
N/A
N/A
N/A
142-222 ohms
GR/W- BR/GR
Ligthing Coil
0,17-0,26 ohms
Y - Y
0,12-0,18 ohms
Y - Y
0,08-0,12 ohm
Y - Y
0,08-0,12 ohms
Y - Y
injection Coil
N/A
N/A
15,2-22,8 ohms
BL/W - BL/W
15,2-22,8 ohms
BL/W-BL/W
Fuel Pump Coil
N/A
N/A
1,52-2,28 ohms
OR-OR
1,52-2,28 ohms
OR-OR
Spark Plug Cap
4000 - 6000 ohms
Cap End - Cap End
4000-6000 ohms
Cap end-Cap end
4000-6000 ohms
Cap end - Cap end
4000-6000 ohms
Cap end - Cap end

Resistance Tests Chart 2006

ITEM
EFI Models
500 cc
(Carb)
570 cc
370/440 cc
700 cc
(Carb)
Ignition Coil - Primary
0.30 ± 20%
B/OR - OR/B
0.34 ± 20%
OR/B - B/OR
0.30 ± 15%
OR - B
0.30 ± 15%
OR - B
0.30 ± 20%
OR - B
Ignition Coil - Secondary
8500 ± 20%
HT - HT
8500 ± 20%
HT - HT
8500 ± 20%
HT - HT
8500 ± 20%
HT - HT
8500 ± 20%
HT - HT
Lighting Coil
0.10 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.22 ± 20%
Y - Y
0.10 ± 20%
Y - Y
Stator Coil (Charge)
N/A
N/A
N/A
160 ± 20%
R/W - B/R
N/A
(DC Power)
N/A
0.89 ± 20%
R/Y - Y/R
N/A
N/A
0.89 ± 20%
R/Y - Y/R
(Charge 1)
17 ± 20%
BR - GR
N/A
15 ± 20%
B/R - G/R
N/A
N/A
(charge 2)
17 ± 20%
BR/W - G/R
N/A
15 ± 20%
BR/W - G/R
N/A
N/A
Ignition Timing Sensor
190 ± 20%
G/W - BR
185 ± 20%
G/W - BR/G
185 ± 20%
G/W - BR
N/A
185 ± 20%
Injector Coil
19 ± 20%
BL/W - BL/W
N/A
N/A
N/A
N/A
Fuel pump Coil
1.9 ± 20%
OR/W - OR/W
N/A
N/A
N/A
N/A
Spark Plug Cap
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20


ABBREVIATION KEY
B Black
G Green
N/A Not Applicable
BL blue
R Red
OR Orange
W White
BR Brown
POS Positive
Y Yellow
GRND Ground
HT High Tension
NEG Negative

Resistance Tests Chart 2005

ITEM
EFI Models
550 cc
500 cc (APV)
500 (Non APV)/ 570
900CC
(Carb)
370/440cc
700cc
"Laydown"
(Carb)
Ignition Coil - Primary
0.30 ± 20%
B/0R - OR/B
0.30 ± 15%
OR - B
0.34 ± 20%
OR - B
0.30 - 15%
OR - B
0.30 ± 20%
OR - B
0.30 ± 15%
OR - B
0.30 ± 20%
OR - B
Ignition Coil - secondary
8500 ± 20 %
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
Lighting Coil
0.10 ± 20%
Y - Y
0.22 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.10 ± 20%
Y - Y
0.22 - 20%
Y - Y
0.10 ± 20%
Y - Y
Stator Coil (Charge)
N/A
N/A
N/A
N/A
N/A
160 ± 20%
R/W - B/R
N/A
(DC Power)
N/A
N/A
0.89 ± 20%
R/Y - Y/R
N/A
0.65 ± 20%
R/Y - Y/R
N/A
0.89 ± 20%
R/Y - Y/R
(Charge 1)
17 ± 20%
B/R -BR/W
160 ± 20%
R/W - B/W
N/A
15 ± 20%
B/R - G/R
N/A
N/A
N/A
(Charge 2)
17 ± 20%
BR/W - G/R
17 ± 20%
B/R - R/W
N/A
15 ± 20%
BR/W - G/R
N/A
N/A
N/A
Ignition Timing Sensor
190 ± 20%
G/W - BR
N/A
185 ± 20%
G/W - BR/G
185 ± 20%
G/W - BR
185 ± 20%
G/W - BR
N/A
185 ± 20%
G/W - BR/GR
Injector Coil
19 ± 20%
BL/W-BL/W
N/A
N/A
N/A
N/A
N/A
N/A
Fuel Pump Coil
1.9 ± 20%
OR/W-OR/W
N/A
N/A
N/A
N/A
N/A
N/A
Spark Plug Cap
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%


ABBREVIATION KEY
B Black
R Red
OR Orange
BL blue
BR Brown
POS Positive
W White
GRND Ground
HT High Tension
Y Yellow
N/A Not Applicable
NEG Negative

Resistance Tests Chart 2004

ITEM
EFI Models
550 cc
500 cc (APV)
500 (Non APV)/ 570
900CC
(Carb)
370/440cc
600/700cc
"Laydown"
(Carb)
Ignition Coil - Primary
0.30 ± 20%
B/0R - OR/B
0.30 ± 15%
OR - B
0.34 ± 20%
OR - B
0.30 - 15%
OR - B
0.30 ± 20%
OR - B
0.30 ± 15%
OR - B
0.30 ± 20%
OR - B
Ignition Coil - secondary
8500 ± 20 %
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
Lighting Coil
0.10 ± 20%
Y - Y
0.22 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.10 ± 20%
Y - Y
0.22 - 20%
Y - Y
0.10 ± 20%
Y - Y
Stator Coil (Charge)
N/A
N/A
N/A
N/A
N/A
160 ± 20%
R/W - B/R
N/A
(DC Power)
N/A
N/A
0.89 ± 20%
R/Y - Y/R
N/A
0.65 ± 20%
R/Y - Y/R
N/A
0.89 ± 20%
R/Y - Y/R
(Charge 1)
17 ± 20%
B/R -BR/W
160 ± 20%
R/W - B/W
N/A
15 ± 20%
B/R - G/R
N/A
N/A
N/A
(Charge 2)
17 ± 20%
BR/W - G/R
17 ± 20%
B/R - R/W
N/A
15 ± 20%
BR/W - G/R
N/A
N/A
N/A
Ignition Timing Sensor
101 ± 20%
190 ± 20%
(600 "LD")
G/W - BR
N/A
185 ± 20%
G/W BR/G
185 ± 20%
G/W B/R
185 ± 20%
G/W B/R
N/A
185 ± 20%
G/W BR/GR
Injector Coil
19 ± 20%
BL/W-BL/W
N/A
N/A
N/A
N/A
N/A
N/A
Fuel Pump Coil
1.9 ± 20%
OR - OR
N/A
N/A
N/A
N/A
N/A
N/A
Spark Plug Cap
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%


ABBREVIATION KEY
B Black
R Red
OR Orange
BL blue
G Green
POS Positive
W White
BR Brown
HT High Tension
Y Yellow
GRND Ground
NEG Negative

N/A Not Applicable


Resistance Tests Chart 2003

ITEM
600/700/800
cc
450cc,
550cc
500 cc
570cc
900CC
370cc
120cc
Ignition Coil - Primary
0.30 ± 20%
0R - B
0.30 ± 15%
OR - B
0.34 ± 20%
OR - B
0.30 - 15%
OR - B
0.30 ± 20%
OR - B
0.30 ± 15%
OR - B
N/A
Ignition Coil - secondary
8500 ± 20 %
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
N/A
Lighting Coil
0.10 ± 20%
Y - Y
0.22 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.10 ± 20%
Y - Y
0.22 - 20%
Y - Y
0.57 ± 20%
Y - Y
Stator Coil (Charge)
N/A
N/A
N/A
N/A
N/A
160 ± 20%
R/W - B/R
N/A
(DC Power)
N/A
N/A
0.89 ± 20%
R/Y - Y/R
N/A
0.65 ± 20%
R/Y - Y/R
N/A
N/A
(Charge 1)
17 ± 20%
B/R - G/R
160 ± 20%
R/W - B/W
N/A
15 ± 20%
B/R - G/R
N/A
N/A
N/A
(Charge 2)
17 ± 20%
BR/W - G/R
17 ± 20%
B/R - R/W
N/A
15 ± 20%
BR/W - G/R
N/A
N/A
N/A
Ignition Timing Sensor
190 ± 20%
G/W - BR
N/A
185 ± 20%
G/W BR/G
185 ± 20%
G/W B/R
185 ± 20%
G/W B/R
N/A
N/A
Injector Coil
19 ± 20%
BL/W-BL/W
N/A
N/A
N/A
N/A
N/A
N/A
Fuel Pump Coil
1.9 ± 20%
OR - OR
N/A
N/A
N/A
N/A
N/A
N/A
Spark Plug Cap
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%


ABBREVIATION KEY
B Black
R Red
OR Orange
BL blue
G Green
POS Positive
W White
BR Brown
HT High Tension
Y Yellow
GRND Ground
NEG Negative

N/A Not Applicable


Resistance Tests Chart 2002

ITEM
600 cc
Twin Carburated
600/800
cc
450cc(Z),
550cc
1000cc
570cc
800cc
(Carburated)
500 cc
600 cc Triple
370cc, 440cc
(Panther)
120cc
Ignition Coil - Primary
0.34 ± 20%
OR - B
0.30 ± 20%
0R - B
0.30 ± 15%
OR - B
0.34 ± 15%
POS - NEG
0.30 - 15%
OR - B
0.30 ± 20%
OR - B
0.34 ± 20%
OR - B
0.34 ± 15%
POS - NEG
0.30 ± 15%
OR - B
N/A
Ignition Coil - secondary
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20 %
HT - HT
7900 ± 20%
HT - HT
HT - POS
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
7900 ± 20%
HT - HT
HT - POS
8500 ± 20%
HT - HT
N/A
Lighting Coil
0.15 ± 20%
Y - Y
0.10 ± 20%
Y - Y
0.22 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.10 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.22 - 20%
Y - Y
0.57 ± 20%
Y - Y
Stator Coil (Charge)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
160 ± 20%
R/W - B/R
N/A
(DC Power)
0.89 ± 20%
R/Y - Y/R
N/A
N/A
N/A
N/A
0.65 ± 20%
R/Y - Y/R
0.89 ± 20%
R/Y - Y/R
0.89 ± 20%
R/Y - Y/R
N/A
N/A
(Charge 1)
N/A
17 ± 20%
B/R - G/R
160 ± 20%
R/W - B/W
15 - 20%
B/R - G/R
15 ± 20%
B/R - G/R
N/A
N/A
N/A
N/A
N/A
(Charge 2)
N/A
17 ± 20%
BR/W - G/R
17 ± 20%
B/R - R/W
15 - 20%
BR/W - G/R
15 ± 20%
BR/W - G/R
N/A
N/A
N/A
N/A
N/A
Ignition Timing Sensor
190± 20%
G/W - BR
190 ± 20%
G/W - BR
N/A
190 ± 20%
G/W -BR
185 ± 20%
G/W- B/R
185 ± 20%
G/W- B/R
190± 20%
G/W - BR
190± 20%
G/W - BR
N/A
N/A
Injector Coil
N/A
19 ± 20%
BL/W-BL/W
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Fuel Pump Coil
N/A
1.9 ± 20%
OR - OR
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Spark Plug Cap
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%


ABBREVIATION KEY
B Black
R Red
OR Orange
BL blue
G Green
POS Positive
W White
BR Brown
HT High Tension
Y Yellow
GRND Ground
NEG Negative

N/A Not Applicable


Resistance Tests Chart 2001

ITEM
600 cc
Twin Carburated
600cc EFI
550cc
800cc Trile
1000cc
500cc EFI
580cc EFI
800cc
Twin
500 cc
(Carburated)
600 cc Triple
370cc, 440cc
Ignition Coil - Primary
0.092± 15%
OR - B/W
0.30 ± 15%
0R - B
0.30 ± 15%
OR - B
0.34 ± 15%
POS - NEG
0.30 - 15%
OR - B
0.30 ± 15%
OR - B
0.30± 15%
OR - B
0.34 ± 15%
POS - NEG
0.30 ± 15%
OR - B
Ignition Coil - secondary
4400± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20 %
HT - HT
7900 ± 20%
HT - HT
HT - POS
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
7900 ± 20%
HT - HT
HT - POS
8500 ± 20%
HT - HT
Lighting Coil
0.20± 20%
Y - Y
0.10 ± 20%
Y - Y
0.22 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.09± 20%
Y - Y
0.16± 20%
Y - Y
0.15 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.22 - 20%
Y - Y
Stator Coil (Charge)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
160 ± 20%
R/W - B/R
(DC Power)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
(Charge 1)
46±20%
G-G
17 ± 20%
B/R - G/R
160 ± 20%
R/W - B/W
15 - 20%
B/R - G/R
46 ± 20%(high)
B -G
17± 20%
B/R - G/R
46±20%(high)
G-B/R
20 ± 20%
G B/R
N/A
(Charge 2)
N/A
17 ± 20%(high)
G/R- BR/W
17 ± 20%
B/R - R/W
15 - 20%
BR/W - G/R
450±20%(low)
BR - G
17 ± 20%
G/R - BR/W
450±20%(low)
G - W
450 ± 20%
G/W - B/R
N/A
Ignition Timing Sensor
101± 20%
G/W - BR
190 ± 20%
G/W - BR
N/A
101± 20%
G/W -BR
190±20%(580cc)
G/W- BR
101 ± 20%
G/W- B/R
101 ± 20%
G/W - BR
190± 20%
G/W - BR
N/A
Injector Coil
N/A
19 ± 20%
BL/W-BL/W
N/A
N/A
21 ± 20%
BL - BL
N/A
N/A
N/A
N/A
Fuel Pump Coil
N/A
1.9 ± 20%
OR - OR
N/A
N/A
1.8 ± 20%
OR - OR
N/A
N/A
N/A
N/A
Spark Plug Cap
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%


ABBREVIATION KEY
B Black
R Red
OR Orange
BL blue
G Green
POS Positive
W White
BR Brown
HT High Tension
Y Yellow
GRND Ground
NEG Negative

N/A Not Applicable


Resistance Tests Chart 2000

ITEM
600 cc
Twin Carburated
600cc EFI
550cc
800cc Trile
1000cc
500cc EFI
580cc EFI
800cc
Twin
500 cc
(Carburated)
600 cc Triple
340cc,370cc, 440ccF/C
440cc L/C
Ignition Coil - Primary
0.092± 15%
OR - B/W
0.30 ± 15%
0R - B
0.30 ± 15%
OR - B
0.34 ± 15%
POS - NEG
0.30 - 15%
OR - B
0.30 ± 15%
OR - B
0.30± 15%
OR - B
0.34 ± 15%
POS - NEG
0.30 ± 15%
OR - B
0.092± 15%
OR - B/W
Ignition Coil - secondary
4400± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20 %
HT - HT
7900 ± 20%
HT - HT
HT - POS
8500 ± 20%
HT - HT
8500 ± 20 %
HT - HT
8500 ± 20%
HT - HT
7900 ± 20%
HT - HT
HT - POS
8500 ± 20%
HT - HT
4100±15%
HT - HT
Lighting Coil
0.20± 20%
Y - Y
0.10 ± 20%
Y - Y
0.22 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.09± 20%
Y - Y
0.16± 20%
Y - Y
0.15 ± 20%
Y - Y
0.15 ± 20%
Y - Y
0.22 - 20%
Y - Y
0.11 ± 10%
Y - Y
Stator Coil (Charge)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
160 ± 20%
R/W - B/R
N/A
(DC Power)
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
(Charge 1)
46±20%
G-G
17 ± 20%
B/R - G/R
160 ± 20%
R/W - B/W
15 - 20%
B/R - G/R
46 ± 20%(high)
B -G
17± 20%
B/R - G/R
46±20%(high)
G-B/R
20 ± 20%
G B/R
N/A
1260± 10%
G- B/W
(Charge 2)
N/A
17 ± 20%(high)
G/R- BR/W
17 ± 20%
B/R - R/W
15 - 20%
BR/W - G/R
450±20%(low)
BR - G
17 ± 20%
G/R - BR/W
450±20%(low)
G - W
450 ± 20%
G/W - B/R
N/A
16 ± 10%
W/R - B/W
Ignition Timing Sensor
101± 20%
G/W - BR
190 ± 20%
G/W - BR
N/A
101± 20%
G/W -BR
190±20%(580cc)
G/W- BR
101 ± 20%
G/W- B/R
101 ± 20%
G/W - BR
190± 20%
G/W - BR
N/A
N/A
Injector Coil
N/A
19 ± 20%
BL/W-BL/W
N/A
N/A
21 ± 20%
BL - BL
N/A
N/A
N/A
N/A
N/A
Fuel Pump Coil
N/A
1.9 ± 20%
OR - OR
N/A
N/A
1.8 ± 20%
OR - OR
N/A
N/A
N/A
N/A
N/A
Spark Plug Cap
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%
5000 ± 20%


ABBREVIATION KEY
B Black
R Red
OR Orange
BL blue
G Green
POS Positive
W White
BR Brown
HT High Tension
Y Yellow
GRND Ground
NEG Negative

N/A Not Applicable


Recensioner Snitt: 0/5
 Ni måste vara inloggad för att kunna skriva en recension

Relaterade produkter

Kundvagn
... din kundvagn är tom
kassan
kundvagn
Partners
Logga in

» Skapa konto
» Glömt lösenord

© www.catmaster.se 2009 - Alla rättigheter reserverade.
E-butik från c4media
